yoRk iNteRNAtioNAl
42
FoRm 180.30-Rpstl
compressor
item no. description
4 cylinder
6 cylinder
8 cylinder
32
Gasket, motor Cover
064-49549-000
064-49548-000
064-49548-000
33
terminal Box
see Figures 46, 57A and 57B and table 4
35
screw, 7/16 Hex Flange (12 or 44 Required)
3
021-17692-000
021-17692-000
021-17692-000
36
pipe plug, 1/4 square Head
023-01972-000
023-01972-000
023-01972-000
No. Required per Compressor
3
4
5
37
pipe plug, 1/4 Hex socket
023-01973-000
023-01973-000
023-01973-000
sealer, loctite
42
(Use with items 10, 12-8,
013-01671-000
013-01671-000
013-01671-000
16-3, 16-5, 88, 140-3 and 242)
43
screw, 1/2 Hex Cap
021-18021-000
021-18021-000
021-18021-000
No. Required per Compressor
24
23
22
44
Gasket (2 Required)
064-47079-000
064-47079-000
064-47204-000
45
screen, suction
026-28473-000
026-28473-000
026-28474-000
46
Valve, suction stop
022-02844-000
022-02844-000
022-02845-000
Valve size
3-1/8”
3-1/8”
3-5/8”
47
screw, 5/8 Hex Cap (4 Required)
021-16817-000
021-16817-000
021-16818-000
48
Gasket, Discharge Valve
064-47078-000
064-47078-000
064-47079-000
49
Valve, Discharge stop
022-01394-000
022-01394-000
022-02844-000
Valve size
2-5/8”
2-5/8”
3-1/8”
50
screw, 5/8 Hex Cap (4 Required)
021-16821-000
021-16821-000
021-16817-000
51
Gasket, terminal Block
064-49545-000
064-49545-000
064-49545-000
52
terminal Block
025-30402-000
025-30402-000
025-30402-000
70
key, motor
064-26560-000
064-26560-000
064-26560-000
71
Washer, shaft
064-21835-000
064-21835-000
064-21835-000
72
lockwasher, 5/8, shaft
021-05295-000
021-05295-000
021-05295-000
73
screw, 5/8 Hex Cap
021-01630-000
021-01630-000
021-01630-000
75
Heat Conductive Compound
013-00898-000
013-00898-000
013-00898-000
(Use with items 202 & 240)
76
screw, 3/8 Hex Flange
—
021-17782-000
021-17781-000
No. Required per Compressor
—
4
4
77
screw, 3/8 Hex Flange
—
021-17781-000
021-19637-000
No. Required per Compressor
—
4
8
80
Retaining Cmpd, loctite (Use with item 2)
013-01752-000
013-01752-000
013-01752-000
s
87
Gasket, solenoid Valve
064-49541-000
064-49541-000
064-49541-000
No. Required per Compressor
1
2
3
88
stud, 1/2
021-30172-000
021-30172-000
021-30172-000
No. Required per Compressor
1
1
2
89
Nut, 1/2 Hex
021-11154-000
021-11154-000
021-11154-000
No. Required per Compressor
1
1
2
90
screw, 3/8 Hex Cap
021-17690-000
021-17690-000
021-17690-000
No. Required per Compressor
6
12
18
92
pipe plug, 1/8 Hex socket
023-01970-000
023-01970-000
023-01970-000
No. Required per Compressor
1
2
3
98
Washer, 1/2, Clipped Circular
021-17774-000
021-17774-000
021-17774-000
No. Required per Compressor
1
1
2
99
screw, 3/8 Hex Flange
—
021-17784-000
021-17784-000
No. Required per Compressor
—
4
4
100
screw, 3/8 Hex Flange
021-17784-000
—
—
No. Required per Compressor
4
—
—
101
Cover plate, Blank
2
064-48187-000
064-48187-000
064-48187-000
No. Required per Compressor
see table 3
134
Drain Orifice Plug, .022”
064-47349-000
064-47349-000
064-47349-000
No. Required per Compressor
1
2
3
136
Conduit w/Connectors
064-49020-001
064-49020-001
064-49020-001
No. Required per Compressor
see Figure 57B and table 3
137
Conduit w/Connectors
—
064-49020-002
064-49020-002
No. Required per Compressor
see Figure 57B and table 3
s
140
Unloader piston
364-48190-000
364-48190-000
364-48190-000
No. Required per Compressor
see Figure 48 and table 3
141
seal, o-ring, Cylinder sleeve
028-12259-000
028-12259-000
028-12259-000
No. Required per Compressor
4
6
8
noteS:
S
= Recommended Stock Spare Part
1
= Not shown. Used for threaded pipe joints unless otherwise specified.
2
= Used to Replace Solenoid Valves for Reduced Steps of Unloading.
3
= See DeSIGN hISTORY
table 2 –
CompRessoR CompoNeNts, GeNeRAl (see FiGURes 46, 47, 48 & 49)
renewal parts
