UNIT MOUNTED INSTRUMENTS

Unit Mounted instruments may be customized for

NEMA 4X units in order to meet the installation en-

vironment, refer to the project IOM for further docu-

mentation.

TABLE 4 -

PRESSURE SENSORS

ITEM

USAGE DESCRIPTION

TAG

PART NUMBER

RANGE

FIGURE

1

Economizer, Oil Sumps,
Oil Pumps Discharge

PE-116,

PE-140A,

PE-140B

025-28678-006

0-300 psi

8,9

2

Evaporator (Heat Pump)

PE-111

025-28678-115

0-125 psi

8

2a

Evaporator (Ice Storage)

PE-111

025-40312-000

0-100 psia

8

3

Condenser

PE-113,

025-44908-000

0-400 psi

9,10

4

Stall Detector

PE-149A,

025-40088-000

0-300 psi

10

PE-149B

025-44908-000
025-43790-004

0-400 psi

0-500 psi

TABLE 5 -

ICTD TEMPERATURE SENSORS

ITEM

USAGE DESCRIPTION

TAG

PART NUMBER

INSERTION  MATERIAL FIGURE

5

CYK Water Boxes Standard

TE-100, TE-101,

TE-102, TE-103

025-43334-001

~3.0 inch

Brass

9

6

—

025-43334-002

~3.0 inch

304SS

7

CYK Evaporator Liquid /
CYK Subcooler Dropleg

TE-111, TE-114

025-43334-003

~3.0 inch

Brass

9

8

025-43334-004

~3.0 inch

304SS

9

Replacement Element for
-001, -002, -003, -004

—

025-43334-005

~3.0 inch

—

*

10

YK Compressor Discharge /
Oil Sump

TE-140A,
TE-140B,

TE-112A,

TE-112B

025-43334-006

~0.5 inch

Brass

9,11

11

025-43334-007

~0.5 inch

304SS

12

Replacement Element for
line -006 and -007

—

025-43334-008

~0.5 inch

—

*

13

Replacement DIN
Connector With Cable Seal

—

025-37805-000

—

—

*

TABLE 6 -

LEVEL SENSORS

ITEM

USAGE DESCRIPTION

TAG

PART NUMBER

LIQUID

FIGURE

13

Subcooler 8” Insertion

LE-114

025-46044-008

Refrigerant

9

13a

Innovative Transmitter Module

025-46338-000

Refrigerant

*

14

Economizer

LE-116

025-40006-000

Refrigerant

8

14a

Hansen Transmitter Module

025-40006-001

Refrigerant

*

15

Oil Sumps

LE-140A,

LE-140B

025-40339-000

Oil

9

NOTE: Items with an * are NOT represented.

TABLE 7 -

MISCELLANEOUS SENSORS
