YORK DIVISION BORG-WARNER
YORK TURBOPAK-MODEL OT
FORM 160.61-RP
Oil PUMP AND MOTOR ASSEMBLY
FIG. 15-
01 L PUMP AND MOTOR ASSEMBLY
Model
Voltage
208-3-60
220/440, 230/460, 240/480-3-60
OIL PUMPS
550/575/600-3-60
380-3-50
415-3-50
500-3-50
Part No.
Part No.
026-16027
026-16441
026-16442
026-17098
026-17099
026-17922
MOTORS
Voltage
3PH, 60Hz.
3PH, 50Hz.
026-17179
026-17180
230/460-3-60
208-3-60
SEAL KIT
575-3-60
230/460-3-60(explosion proof)
SEAL KIT (Consists of seal,
retainer plate, special seal
retainer plate, "O" ring, and
three screws)
026-17178
LUBRICANTS, OILS AND COMPOUNDS
Description
Thread Compound, Ari High Pressure-1/4 Pt. Can
Coating Lubricant-Molykote, Type Z-2 Oz. Can
Oil, York Refrigeration-Type B,-5 Gal. Can
OIL HEATERS
Description
Part No.
Quan.
1500W, 120V
025-17700
Part No.
*464-14934
*364-21508
011-00309
Note: Special heater, emersion style 2, 2500 watt, 120 volt,
used for outdoor installation. Part No. 025-16137.
HIGH OIL TEMP. CONTROL (HOT)
Description
High Oil Temperature (Hot)
High Discharge Temperature
Control (HDTC)
15
Part No.
025-15381-003
025-15381-002
Quan.
Part No.
024-16705
024-16706
024-16707
024-16708
