NOTES:
S
= Recommended Stock Spare Part
1
= Not shown. Used for threaded pipe joints
2
= Used to Replace Solenoid Valves for Reduced Steps of Unloading. See Table 1.
COMPRESSOR
ITEM NO.
DESCRIPTION
4 CYLINDER
6 CYLINDER
8 CYLINDER
55
VALVE, SUCTION STOP
022-02844-000
022-02844-000
022-02845-000
VALVE SIZE
3-1/8"
3-1/8"
3-5/8"
56
SCREW, 5/8 HEX CAP (4 REQUIRED)
021-16817-000
021-16817-000
021-16818-000
57
GASKET (2 REQUIRED)
064-47079-000
064-47079-000
064-47204-000
58
VALVE, DISCHARGE STOP
022-01394-000
022-01394-000
022-02844-000
VALVE SIZE
2-5/8"
2-5/8"
3-1/8"
59
SCREW, 5/8 HEX CAP (4 REQUIRED)
021-16821-000
021-16821-000
021-16817-000
60
GASKET, DISCH VALVE
064-47078-000
064-47078-000
064-47079-000
S
61
SIGHT GLASS, OIL (2 REQUIRED)
026-17581-000
026-17581-000
026-17581-000
62
SEALER, REFRIGERANT PIPE
1
013-02023-000
013-02023-000
013-02023-000
S
63
VALVE, OIL CHARGING
022-01582-000
022-01582-000
022-01582-000
64
CAP, OIL CHARGING VALVE
023-00977-000
023-00977-000
023-00977-000
65
PIPE PLUG, 1/8 HEX SOCKET
023-01970-000
023-01970-000
023-01970-000
NO. REQUIRED PER COMPRESSOR
1
2
3
66
CRANKCASE HEATER - 120V
025-32938-000
025-32938-000
025-32938-000
- 240V
025-32939-000
025-32939-000
025-32939-000
67
HEAT CONDUCTIVE COMPOUND
013-00898-000
013-00898-000
013-00898-000
68
DRAIN ORIFICE PLUG, 0.022"
064-47349-000
064-47349-000
064-47349-000
NO. REQUIRED PER COMPRESSOR
1
2
3
69
PIPE PLUG, 1/8 HEX SOCKET
023-01972-000
023-01972-000
023-01972-000
NO. REQUIRED PER COMPRESSOR
1
2
3
70
SENSOR, OIL TEMP
025-32966-000
025-32966-000
025-32966-000
71
MAGNET (2)
029-22748-000
029-22748-000
029-22748-000
72
COVER PLATE, BLANK
2
064-48187-000
064-48187-000
064-48187-000
73
SEALER, LOCTITE (Use with Item 9)
013-01671-000
013-01671-000
013-01671-000
74
SCREW, 3/8 HEX CAP
021-01458-000
021-01458-000
021-01458-000
75
WASHER
021-01267-000
021-01267-000
021-01267-000
76
SEAL, O-RING, CONDUIT SEAL
028-03292-000
028-03292-000
028-03292-000
NO. REQUIRED PER COMPRESSOR
SEE TABLE 1
OIL RETURN PIPING, PUMP END:
77
CONNECTOR, BEARING HEAD TO HOUSING
364-49283-000
364-49284-000
364-49285-000
78
CONNECTOR, FLARE
023-18955-000
023-18955-000
023-18955-000
NO. REQUIRED PER COMPRESSOR
2
1
1
79
ELBOW
NOT REQUIRED
023-18956-000
023-18956-000
OIL RETURN PIPING, MOTOR END:
80
EDUCTOR, OIL RETURN
022-09716-000
022-09716-000
022-09716-000
81
VALVE, CHECK
022-09741-000
022-09741-000
022-09741-000
82
ELBOW
023-00868-000
023-00868-000
023-00868-000
83
SEAL. O-RING
028-13896-000
028-13896-000
028-13896-000
84
CONNECTOR, EDUCTOR TO CHECK VALVE
364-49345-000
364-49345-000
364-49345-000
85
SEALER, REMOVABLE THREAD
013-01678-000
013-01678-000
013-01678-000
86
ELBOW, STREET 1/4 X 1/4
023-01685-000
023-01685-000
023-01685-000
ITEM NUMBER
STEPS OF
38
39
40
51
54W
72
76
UNLOADING
4 Cyl
6 Cyl
8 Cyl
4 Cyl
6 Cyl
8 Cyl
QUANTITY
1
1
1
1
2
2
2
11
0
1
2
1
2
2
2
2
NA
4
4
13
NA
0
1
2
3
3
3
3
NA
NA
6
15
NA
NA
0
3
TABLE 1
PART QUANTITIES FOR VARIOUS STEPS OF UNLOADING
NA = Not Applicable
