FORM 150.40-RP4
ITEM
DESCRIPTION
FIG.
PART NO.
NO.
NO.
l
Coil, Condenser, L.H.
5
363-30815
2
Coil , Condenser, R.H.
5
363-30814
3
Coil , Condenser, Center
5
363-30816
4
Coil , Condenser, Sub-Cooling
5
363-30859
5
Connection, Dehydrator to Solenoid Valve (#2)
5
066-36722
6
Connection, Liquid Valve to Dehydrator ( #l)
5
066-36719
7
Connection, Liquid Valve to Dehydrator (#2)
5
066-36720
8
Connection, Discharge
(#1)
5
366-36842
9
Connection, Discharge (#2)
5
066-34078
10
Connection, Suction (#1)
5
066-36747
11
Connection, Suction (#2)
5
066-48575
12
Connect·i on, Expansion Valve to Moisture Indicator ( #l)
5
066-36724
13
Connection, Expansion Valve to Moisture Indicator (#2)
5
066-36723
14
Gasket, Discharge /#lj
5
065-23141
15
Gasket, Discharge #2
5
028-08490
16
Gasket, Suction (#1)
5
028-00540
17
Gasket, Suction (#2)
s
028-00864
18
Header, Discharge ( u·1 )
5
366-37606
l 9
Header, Discharge (#2)
5
366-37607
20
Header, Rear, R.H. ( #1)
5
363-33954
21
Header, Rear, L.H. (#2)
5
363-33956
22
Header, Outlet i#ll
5
363-34066
23
Header, Outlet #2
5
363-34064
24
Header, Inlet (#1)
5
363-34062
25
Header, Inlet (#2)
5
363-34059
26
Header, Outlet (#1)
5
363-34068
27
Header, Outlet (#2)
5
363-34070
28
Indicator, Moisture
5
026-15305
29
Sensor, Fan Speed Control (#1)
5
225-17108-005
30
Sensor, Fan Speed Control (#2)
5
225-17108-004
31
Strainer - Drier
5
026-14777-009
32
Valve, Discharge (#1)
5
022-03422
33
Valve, Discharge (#2)
5
022-03727-002
34
Valve, Suction
(#1)
5
022-03727-003
35
Valve, Suction (#2)
5
022-01393
36
Valve, Liquid
5
022-02992
37
Valve, Expansion (#1)
5
025-17119
38
Valve, Expansion (#2)
5
025-17117
39
Valve, Solenoid, Pumpdown (4 SOL) (#1)
5
025-17556
40
Valve, Solenoid, Pumpdown (5 SOL) (#2)
5
025-17464
- Circuit No. l, 20 Ton
- Circuit No. 2, 30 Ton
YORI< DIVISION BORG-WARNER
5
