FORM 155.16-RP
No.
Sym.
Part Description
Part Number
Unit Size
PURGE SYSTEM (Cont.)
116
Belt Guard Gasket
028-09318
ES4 C1-ES14F3
117
Absolute Pressure Gage
026-09261
ES1A1-ES14F3
118
Ball Valve (1/2" N.P.T.I.)
022-02558
ES1A1-ES14F3
119
1SOL
Solenoid Valve (Purge Suction)
025-11509
ES1A1-ES14F3
120
Replacement Solenoid Coil (For 1 SOL)
025-11611
ES 1A1-ES 14F3
121
Spare Parts Kit (For 1 SOL)
025-14536
ES 1A1-ES 14F3
CONTROLS AND PANEL COMPONENTS
122
Elem. Wiring Diagram (ESA, ESB - 60 Hz)
035-02167
ES 1A1-ES 14F3
123.
Elem. Wiring Diagram (ESA, ESB - 50 Hz)
035-02167
ES 1A1-ES9E2
124
Elem. Wiring Diagram (ESA, ESB - 50 Hz)
035-02168
ES 10E3-ES 14F3
125
Elem. Wiring Diagram (ESC- ESH - 60 Hz)
035-02166
ES 1A1-ES 14F3
126
Elem. Wiring Diagram (ESC- ESH - 50 Hz)
035-02166
ES 1A1-ES9E2
127
Elem. Wiring Diagram (ESC- ESH- 50 Hz)
035-02165
ES 10E3-ES 14F3
128
Conn. Wiring Diagram (ESA - 60 Hz)
035-02174
ES 1A 1-ES 14F3
129
Conn. Wiring Diagram (ESA - 50 Hz)
035-02174
ES1A1-ES9E2
130
Conn. Wiring Diagram (ESA - 50 Hz)
035-02176
ES 10E3-ES 14F3
131
Conn. Wiring Diagram (ESB - 60 Hz)
035-02173
ES 1A1-ES 14F3
132
Conn. Wiring Diagram (ESB - 50 Hz)
035-02173
ES1A1-ES9E2
133
Conn. /Viring Diagram (ESB - 50 Hz)
035-02175
ES 10E3-ES 14F3
145
Conn. Wiring Diagram (ESC, ESE, ESG - 60 Hz)
035-02172
ES 1A1-ES 14F3
135
Conn. Wiring Diagram (ESC, ESE, ESG - 50 Hz)
035-02172
ES 1A1-ES9E2
136
Conn. Wiring Diagram (ESC, ESE, ESG - 50 Hz)
035-02170
ES 10E3-ES 14F3
137
Conn. Wiring Diagram (ES
□,
ESF, ESH - 60 Hz)
035-02171
ES 1A1-ES 14F3
138
Conn. Wiring Diagram (ES
□,
ESF, ESH - 50 Hz)
035-02171
ES 1A1-ES9E2
139
Conn. Wiring Diagram (ES
□,
ESF, ESH - 50 Hz)
035-02169
ES 10E3-ES 14F3
140
ewe
Controller (Pneu.), Chilled Water
022-02793
ES1A1-ES14F3
141
cws
Chilled Water Temperature Sensor
022-04849
ES 1 A 1--ES 14F3
142
Instruction Drawing (For CWC)
066-12404
ES1A1-ES14F3
143
Key ( CW C Adjustment)
025-13356
ES 1A1-ES 14F3
144
Separable Well (For CWS)
026-14175
ES1A1-ES14F3
145
HLC(RHW)
Controller, Hi Limit (Recirculated Hot Water)
026-18748
ES 1A1-ES 14F3
146
2PRV,3PRV
Pressure Reducing Valve (Pneu.)
022-01897
ES 1A1-ES 14F3
147
1 PE,2PE
Pressure Control Switch (Pneu.-Elect.)
025-09961
ES 1A1-ES 14F3
148
2 G-7 G
Gage, Pressure
026-10301
ES 1A1-ES 14F3
149
2SOL
Air Solenoid Valve (3-Way)
225-11931-006
ES1A1-ES14F3
150
6SOL
Air Solenoid Valve (3-Way)
025-18083
ES 1A1-ES 14F3
151
Replacement Solenoid Coil (For 6SO L)
025-18580
ES 1A1-ES 14F3
152
1RES
Air Restrictor
026-13858
ES 1A1-ES 14F3
153
Pneumatic Tubing - Plastic (1/4 0.D. x 120" Lg.)
067-76683
ES 1A1-ES 14F3
154
1TH
Low Temperature Refrig. Thermostat
025-18086
ES 1A1-ES 14F3
155
TS
Temperature Sensor
025-17896-001
ES 1A1
156
TS
Temperature Sensor
025-17896-002
ES 1A2-ES 14F3
157
Electronic Test Device (For 1TH, TS)
025-18391
ES1A1-ES14F3
158
6TH
AD C Control Thermostat
025-17892
ES 1A1-ES 14F3
159
8TH
Tower Thermostat Water
025-14464
ES 1A1-ES 14F3
160
1TR
Dilution Timer (Steam Units)
325-16341-001
ES1A1-ES14F3
161
1TR
Dilution Timer (Hot Water Units)
32 5-1 6341-004
ES 1A1-ES 14F3
162
2TR
AD C Control Timer
325-16341-005
ES 1A1-ES 14F3
163
1R
Relay, 3 Pole
024-17027
ES 1A1-ES 14F3
164
2R
Relay, 2 Pole
024-17075
ES1.A1-ES14F3
165
3R
Relay, Time Delay
024-14967
ES 1A1-ES 14F3
166
4R
Relay, 1 Pole
024-16395-014
ES1A1-ES14F3
167
1TB
Terminal Block, 3 Pole
025-07725
ES 1A1-ES 14F3
168
2T B
Terminal Block, (34 Reqd.)
025-15865
ES1A1-ES14F3
169
2T B
Terminal End Block
025-13981
ES 1A1-ES 14F3
170
1S
Service Switch, Toggle
024-11735
ES1A1-ES14F3
5
