RENEWAL
PARTS
Supersedes: Nothing
I Form 150. 21-RP
369 ___________
1
PACKAGED LIQUID CHILLERS
HERMETIC TYPE-20 TO 40 TONS
REFRIGERANT -2 2
TABLE 1-
2-5/8" Bore Hermetic Compressors Used On Model LCH Chillers
Description
LCH20W,
LCH25W,
LCH25A
LCH30W,
LCH30A
E&A
E
E
Model
H51SN
H61SN
H61SP
H62SP
H62SQ
Bore X Stroke 2-5/8 X 1-7/8 2-5/8X 1-7/8 2-5/8 X 1-7/8 2-5/8 X 2-1/4 2-5/8 X 2-1/4
No. of Cyl.
6
6
6
6
6
(Std, Compr,)
No. of
5*
6
6
6
6
Active Cyl,
PART NO.
208-3-60
365-22699
365-22701
365-22703
365-22707
365-22709
220/240-3-60
365-22406
365-22409
365-22412
365-22418
365-22421
440/480-3-60
365-22407
365-22410
365-22413
365-22419
365-22422
550/600-3-60
365-22408
365-22411
365-22414
365-22420
365-22423
220-3-50
365-22700
365 -22702
365-22704
365-22708
365-22710
380/400-3-50
365-23182
365-23182
365-23184
365-23186
365-23187
*Suction Valve Removed From One Cylinder
For all Compressor Parts refer to Renewal Parts Form 180.15-RPl.
LCH40W,
LCH40A
E
H92SR
H92SS
2-5/8 X 2-1/4 2-5/8 X 2-1/4
9
9
9
9
365-22715
365-22717
365-22430
365-22433
365-22431
365-22434
365-22432
365-22435
365-22716
365-22718
365-23190
365-23191
Compressors are bare, with discharge manifold, stop valves, oil charge and crankcase heater, less base.
Compressor part numbers shown. are for compressors with suction pressure actuated capacity control.
Compressors used on LCH model chillers are equipped with temperature actuated capacity control. For
replacement, order compressor listed above and use power assembly from original compressor or order
new power assembly (part number 025-09981).
NOMENCLATURE
LC
H 20 E
Liquid Chiller
Hermetic Compressor
Nominal Capacity - Tons
Model Designation:
W - Water Cooled Condenser Model
E - Condenserless model for remote
water cooled or evaporative con
denser using same motor as water
cooled model.
A - Condenserless model for air
cooled condenser using larger
motor than W or E model.
MODELS
I
LCH20W, E, A
LCH25W, E, A
LCH30W, E, A
LCH40W, E, A
•
