Min Flow Max Flow
dp@Max Min Flow
Max Flow dp@Maxx
Part Number
Size
(ft
3
/hr) (ft
3
/hr) (psi) (ft
3
/hr) (ft
3
/hr) (psi)
R405-4080
½
" 263 3810 1.27 307 5200 1.73
R405-4081
¾
" 485 7040 1.27 566 9610 1.73
R405-4047
1
806
16700
2.57
942
22800
3.52
R405-4271
1
½
" 1980 49300 3.72 2320 67300 5.08
R405-4088
2"
3310
82400
3.72
3870
112000
5.08
R405-4084
3"
7400
184000
3.72
8650
251000
5.08
R405-4275
4"
12900
320000
3.72
15050
438000
5.08
Min Flow Max Flow
dp@Max
Min Flow
Max Flow
dp@Max
Part Number
Size
(ft
3
/hr) (ft
3
/hr) (psi) (ft
3
/hr) (ft
3
/hr) (psi)
R405-4080
½
" 345 6600 2.20 280 7990 2.66
R405-4081
¾
" 638 12100 2.20 702 14760 2.66
R405-4047
1
1060
28900
4.46
1170
35000
5.40
R405-4271 1
½
" 2610 85400 6.46 2870 103000 7.79
R405-4088
2"
4360
142000
6.46
4790
172000
7.79
R405-4084
3"
9740
319000
6.46
10800
386000
7.79
R405-4275
4"
17000
555000
6.46
18700
672000
7.79
Min Flow Max Flow
dp@Max
Part Number
Size
(gal/hr)
(gal/hr)
(psi)
R405-4080
½
" 250 1310 11.7
R405-4081
¾
" 339 2420 11.7
R405-4047
1
437
4030
11.7
R405-4271
1
½
" 685 9910 11.7
R405-4088
2"
885
16500
11.7
R405-4084
3"
1330
37000
11.7
R405-4275
4"
2150
64500
11.7
Conditions: Natural Gas, 60°F, 0 fasl Elevation continued
40 psi
60 psi
60 psi
80 psi
100 psi
Conditions #2 Fuel Oil, 60°F, 0 fasl Elevation
(inlet pressure do es not aff ect below data)
