Values shown in both charts are nominal. If normal fl ows exceed actuation rates by less than 10%, custom vanes are recommended. Figures are based
on standard vertical installation in a 1½ " thredolet in a horizontal run of pipe.
VANE
LAYERS 3" Pipe
4" Pipe
6" Pipe
8" Pipe
10" Pipe
12" Pipe
14" Pipe
16" Pipe
18" Pipe
20" Pipe
1 45-22
95-40
210-120
375-175
600-300
900-450
1200-600
1400-800
2000-1000
2400-1200
10-5
22-9
48-27
85-40 138-68
204-102
273-136
318-182
454-227
545-273
1
&
2
23-14
50-35
130-90
230-150
450-250
650-350
900-500
1200-650
1450-800
1800-1000
5.2-3.2 11.4-7.9 30-20
52-34
102-57
148-79
204-114 2735-148
329-182
409-227
1, 2,
&
3
11-7
27-19
80-60
160-115
300-180
450-275
600-350
750-450
1000-600
1200-700
2.5-1.67 6.1-4.3 18-14
36-26
68-41
102-62
136-79
165-125
227-136
273-159
1, 2, 3,
&
17-124
60-45
120-90
230-150
310-200
430-280
550-360
700-450
850-550
4
3.9-2.7
14-10
27-20
52-34
70-45
98-64
125-821
159-102
193-125
1, 2, 3, 4,
40-30
80-65
135-100
200-140
290-200
360-250
460-325
575-400
&
5
9.1-6.8
18-15
31-23
45-32
66-45
82-578
104-74
131-91
Actuation rates are based on cold water at a specifi c gravity of 1.0. For fl uids of diff erent gravity, actuation rates may be approximated by dividing
the rate shown by the square root of the specifi c gravity.
VANE
LAYERS
3" Pipe 4" Pipe 6" Pipe
8" Pipe
10" Pipe
12" Pipe
14" Pipe
16” Pipe
18" Pipe
20" Pipe
1 210-105
400-200
950-475
1550-850
2400-1300
3450-1900
4700-2600
6400-3500
8000-4400
10000-5500
.10-.05
.19-.09
.45-.22
.73-.40
1.1-0.6
1.6-0.9
2.2-1.2
3.0-1.78 3.8-2.1
4.7-2.6
1
&
2
120-70
195-140 550-375
1100-700 1850-1200 2700-1750 3400-2200 4800-3100
6000-3900
7400-4800
.06-.03
.09-.07
.26-.18
.52-.33
.87-.57
1.3-0.8
1.6-1.0
2.3-1.5 2.8-1.8 3.5-2.3
1, 2,
&
3
60-48
135-100 375-265
725-500
1200-850
1850-1300 2600-1800 3350-23500 4300-3000
5300-3700
.03-.02
.06-.05
.18-.13
.34-.24
.57-.40
.87-.61
1.2-0.8
1.6-1.1 2.0-1.4 2.5-1.7
1, 2, 3,
&
65-50
260-200
500-400
875-700
1250-1000 1900-1500 2500-2000
3100-2500
3900-3100
4
.03-.02 .12-.09
.24-.19
.41-.33
.59-.47
.90-.71
1.2-0.9
1.5-1.2
1.8-1.5
1, 2, 3, 4,
130-100
310-250
650-525
1000-800 1600-1250 2200-1750
2800-2550
3550-2850
&
5
.06-.05
.15-.12
.31-.25
.47-.38
.76-.59
1.04-0.83
1.3-1.1
1.7-1.3
Actuation rates are based on air at standard conditions.
ORDERING INFORMATION
:
For Horizontal Pipe
8590A-H Vane Operated Flow Switch with cordset and
receptacle, fi eld sadjustable, 3" to 20" Pipe
Horizontal Vane Flow Switch only R830-6731
20 Electrical Cordset EMR-889-F4AFC-20F
Electrical Receptacle EMR-889-M4AF1-1F
For Vertical Pipe (fl ow going up only)
8590A-V Vane Operated Flow Switch with cordset and
receptacle, fi eld adjustable, 3" to 20" Pipe
Vertical Vane Flow Switch only R830-6725
20 Electrical Cordset EMR-889N-F4AFC-20F
Electrical Receptacle EMR-889N-M4AF1-1F
8
(203.2)
6¾
(171.45)
411⁄16
(119.06)
1
(25.4)
311⁄32
(84.93)
2½
(63.5)
EXPLOSION-PROOF
HOUSING WITH ¾
"
CONDUIT CONNECTION
SWITCH BODY OF SÆ 72
BRASS OR 316 STAINLESS
STEEL
1½ " NPT
MAGNET KEEPER 430
STAINLESS STEEL
VANE and VANE BLOCK
316 STAINLESS STEEL
FIVE LAYER VANE DESIGNED
FOR 1½ " TO 20" PIPES.
UL and CSA TYPE
INCLUDES 16 GA.
LEADS, 6" LONG.
DIMENSIONS
inches (mm)
DIMENSIONS SHOWN ARE SUBJECT TO CHANGE. PLEASE OBTAIN CERTIFIED PRINTS FROM FIVES NORTH AMERICAN COMBUSTION, INC.
IF SPACE LIMITATIONS OR OTHER CONSIDERATIONS MAKE EXACT DIMENSION(S) CRITICAL
.
TABLE 1: APPROXIMATE ACTUATION/DE-ACTUATION FLOW RATES
UPPER FIGURES IN GPM. LOWER FIGURES IN M3/HR
TABLE 2: APPROXIMATE ACTUATION/DE-ACTUATION FLOW RATES FOR AIR.
UPPER FIGURES IN SCFM. LOWER FIGURES IN NM
3
/S
