CAPACITIES

gph

0.85 sp gr oil at 48 SSU

7142A and 7152A Regulators

viscosity/sp gr

correction factors

Multiply gph in tables by factor†.



oil viscosity

 grade

SSU

factor

 4,5,6

  100

0.9

 4



  300

    

0.85

 6

2000  0.5

 5

4000  0.4

 6

5000  0.3







10% 20% 10% 20% 10% 20%

 pressure,





psig droop droop droop droop droop droop

outlet inlet

gph gph gph gph gph gph



  60  495

846

    

846 1392  1132  1952



  75  553

943

    

943 1529 1366 2342



100  651

1106  1106  1757  1757  2993



150  716

1171

1204  1887  1887  3123



200  782

1237  1301  2017  2018  3254



250  879  1269  1334  2083  2473  3742



  60  442

852

    

865  1483

  

1106 1952



  75  520

911

   

911 1562 1171 2017



100  585

1106

1171

1887  1626  2668



150  651

1171  1366  2212  1757  3123



200  715

1236  1562  2538  1887  3579



250  813

1367  1594  2538  2343  3969



100  651

1171

1171

1952  1431  2472



125  735  1269  1334  2166  1789  3013



150  813  1366  1497  2375  2148  3546



200  976  1562  1822  2798  2863  4620



250  1008  1627  1953  3026  3026  4815



½

"

¾

" 1"

Bulletin 7142A/52A

Page 2

30 psig

(15 to 30

psig

spring)

50 psig

(25 to 75

psig

spring)

75 psig

(70 to 150

psig

spring)

  †  When choosing factors for
    heavier oils, make sure oil
    temperature required for
     desired SSU value dœ s not
     exceed regulator temperature
     rating.

7142A and 7152A Regulators reduce oil or compressed air line
pressures (up to 250 psig) to a reduced constant outlet pressure.

7142A REGULATOR (for light oil and air)

7142A Regulators are frequently installed upstream of North
American 7052 Air/Oil Ratiotrols, which require 25-30 psig inlet
pressures.

Standard 7142A Regulator spring range is 15-30 psig, 25-75 psig
or 70-150 psig outlet--it is factory set for 30 psig.

Body: cast iron with brass trim.

Diaphragm: neoprene.

Seat: Nitrile.

Maximum temperature:  180°F.

Outlet pressure is adjusted by loosening locknut and turning
spring adjusting screw on top of regulator, then tightening
locknut.

More trim options are available upon request to Fives North
American Combustion, Inc.

7152A REGULATOR (for heavy oil)

Standard spring range is 15-30 psig, 25-75 psig or 70-150 psig
outlet, factory set for 70 psig.

Body: cast iron with stainless steel trim.

Diaphragm: Viton.

Seat: Tefl on.

Maximum temperature: 300°F.

Product Overview | Pressure Regulators
