Dimensions in inches
Approximate
Blower Designation
Filter Designation
E
N
R
weight in lb
2416-D-—7.5, 10
2923-18-D
24
¼
10 18
5⁄8
50
2416-F-—15, 20
2923-22-F
27
¾
12 22
5⁄8
80
2416-F-—25, 30
2923-22.5-F
33
¾
12 22
5⁄8
88
2320-19/2-—1.5
2923-8-19A
18
3⁄8
3
8
5⁄8
16
2320-19/2-—2, 3
2923-8-19B
18
7⁄8
4
8
5⁄8
16
2320-26/2-—5
2923-10-26A
21
7⁄8
6
10
5⁄8
24
2320-26/2-—7.5
2923-12-26A
23
7⁄8
6
12
5⁄8
32
2320-35/1-—10
2923-14-35B
24
5⁄8
8 14
5⁄8
57
2320-35/2-—10
2923-14-35A
28
8
14
5⁄8
57
2320-35/2-—15
2923-18-35A
32
1⁄8
8 18
5⁄8
73
2320-35/1-—15
2923-18-35B
28
¾
8
18
5⁄8
73
2320-21/1-—15
2923-18-21A
28
5⁄8
10 18
5⁄8
94
2320-21/1-—20
2923-22-21A
32
5⁄8
10 22
5⁄8
115
2320-33/1-—25, 30
2923-22.5-33A
40
½
12 22
5⁄8
205
2320-33/1-—40 2923-30-33A
42
½
12 30
5⁄8
260
2320-41/1-—25, 30, 40
2923-30-41A
49
3⁄8
16 30
5⁄8
284
2420-F-—15
2923-18-F
24
¼
12 18
5⁄8
50
2420-F-—20, 25
2923-22-F
27
¾
12 22
5⁄8
80
2420-F-—30
2923-22.5-F
33
¾
12 22
5⁄8
88
2324-14/3-—1.5, 2
2923-8-14A
20
3
8
5⁄8
16
2324-19/2-—3
2923-8-19B
19
1⁄8
4
8
5⁄8
16
2324-26/2-—5
2923-10-26A
21
7⁄8
6
10
5⁄8
24
2324-26/2-—7.5
2923-12-26A
23
7⁄8
6
12
5⁄8
32
2324-35/2-—10
2923-14-35A
28
8
14
5⁄8
57
2324-35/2-—15
2923-18-35A
32
1⁄8
8 18
5⁄8
73
2324-21/1-—20
2923-18-21A
28
3⁄8
10 18
5⁄8
94
2324-33/1-—25, 30
2923-22-33A
34
½
12 22
5⁄8
147
2324-41/1-—30, 40
2923-30-41A
49
3⁄8
16 30
5⁄8
284
2324-33/1-—40 2923-30-33A
42
½
12 30
5⁄8
260
2324-41/1-—50 2923-30-41A
49
3⁄8
16 30
5⁄8
284
2424-F-—20
2923-18-F
24
½
12 18
5⁄8
50
2424-F-—25, 30
2923-22-F
27
¾
12 22
5⁄8
80
2332-19/3-—3, 5
2923-8-19B
22
¾
4
8
5⁄8
16
2332-28/2-—7.5, 10, 15
2923-14-28A
29
½
8
14
5⁄8
57
2332-21/2-—20, 25, 30
2923-18-21A
33
7⁄8
10 18
5⁄8
94
2332-21/2-—40
2923-22-21A
37
7⁄8
10 22
5⁄8
115
2332-33/2-—50 2923-22.5-33A
46
7⁄8
12 22
5⁄8
205
2332-33/2-—60 2923-30-33A
48
7⁄8
12 30
5⁄8
260
2332-41/2-—75 2923-30-41A
60
1⁄8
16 30
5⁄8
284
2338-41/2-—75 2923-30-41A
60
1⁄8
16 30
5⁄8
284
2344-28/3-—15, 20
2923-14-28A
35
8
14
5⁄8
57
2344-21/2-—30, 40
2923-18-21A
35
¾
10 18
5⁄8
94
2344-21/2-—50
2923-22-21A
39
¾
10 22
5⁄8
115
See Sheet 2923-1 for 50 hertz Direct Drive Blowers.
When installing blower, allow suffi
cient space beyond fi lter for removal for cleaning.
Approximate weight includes fi lter and fl ange.
Nominal pipe size of fi lter adapter. 6" size and smaller are threaded.
Bulletin 2923
Page 4
Dimensions | Blower Filters
