North American Series 2400 - 50 Hertz
Direct Drive Blowers - Specifi cations
Sheet 2400-4
Nominal pipe
50 hertz
Vol.,
Pressure,
size, inches
Equivalent 60 hertz blower
Blower
designation
cfm
†
osi
In
Out
for dimensions and weights
24055-D-T3D‡
1100
5.9
10
10
2408-D-5
24055-D-__5D
1500
5.6
10
10
2408-D-7.5
24055-F-T7.5D‡
2500
6.3
12
12
2408-F-15
24055-F-__10D
2900
6.7
12
12
§
2408-F-20
24055-G-__15D
5750
5.6
20 16
2408-G-25
24055-G-__20D
6700
6.6
20 18
2408-G-40
24055-G-__25D
8100
6.7
20 20
2408-G-50
24055-G-__30D
9700
5.0
20 24
2408-G-50
24055-H-__30D
9500
6.8
20 24
2408-H-50
24085-D-__5D
1350
8.0
10
10
2412-D-7.5
24085-D-__7.5D
1620
8.0
10
10
2412-D-10
24085-F-T7.5D‡
1910
8.0
12
12
2412-F-10
24085-F-__10D
2550
8.2
12
12
2412-F-15
24085-F-__15D
3050
8.5
12
12
§
2412-F-20
24085-G-__15D
4500
8.4
20 16
2412-G-25
24085-G-__20D
6000
8.1
20 16
2412-G-30
24085-G-__25D
7150
8.5
20 18
2412-G-40
24085-G-__30D
8500
8.0
20 20
2412-G-50
24085-G-__40D
9400
8.0
20 24
2412-G-60
2411-D-__5D
1100
11.0
10
10
2416-D-7.5
2411-D-__7.5D
1400
10.8
10
10
2416-D-10
2411-F-T7.5D‡
1550
11.9
12
12
2416-F-15
2411-F-__10D
2100
12.4
12
12
2416-F-20
2411-F-__15D
3100
11.3
12
12
§
2416-F-25
2411-F-__20D
3600
10.0
12
12
§
2416-F-30
2411-G-__20D
4500
11.3
20 16
2416-G-30
2411-G-__25D
6000
11.0
20 18
2416-G-40
2411-G-__30D
7200
11.0
20 20
2416-G-50
2414-F-T7.5D‡
1100
14.0
12
12
2420-F-15
2414-F-__10D
1800
14.5
12
12
2420-F-20
2414-F-__15D
2500
14.7
12
12
§
2420-F-25
2414-F-__20D
3000
14.0
12
12
§
2420-F-30
24165-F-__10D
1100
17.1
12
12
2424-F-20
24165-F-__15D
2200
17.0
12
12
2424-F-25
24165-F-__20D
2800
16.1
12
12§
2424-F-30
†Service Factor is 1.0 on all 50 hertz motors.
‡TEFC
only.
§For an average situation a 14" discharge pipe is recommended but length of run should determine size.
