LEx LEX
Capacity
Primary Max.
Maximum
Flame
Flame
Designation
(Btu/h HHV) @
LEx Total Fuel
Primary Air
Fuel
Radial Air Radial Fuel Length Diameter
60% XSA
Flow (scfh)
Flow
Flow
Flow
Flow
(ft )
(ft )
4213-2
3,600,000
3,500
53,000
3,400
—
520
5.0
0.8
4213-3
4,300,000
4,200
63,000
4,100
—
620
5.0
0.9
4213-5
5,700,000
5,500
84,000
5,400
—
830
5.0
1.0
4213-6
7,000,000
6,800
104,000
6,700
—
1,000
5.5
1.0
4213-7
8,200,000
8,000
122,000
7,800
—
1,200
5.5
1.1
4213-8
9,400,000
9,000
139,000
8,800
—
1,400
5.5
1.2
4213-10
12,900,000
12,500
191,000
12,300
—
1,900
6.0
1.3
4213-12
15,500,000
15,100
230,000
14,800
—
2,300
6.0
1.4
4213-14
18,100,000
17,600
268,000
17,300
—
2,600
6.0
1.5
4213-19
22,200,000
21,700
330,000
21,300
—
3,300
7.0
1.6
4213-22
26,700,000
26,000
395,000
25,500
8,800
3,900
7.0
1.8
4213-27
31,100,000
30,400
461,000
29,800
10,300
4,600
7.0
2.0
4213-29
35,500,000
34,700
527,000
34,000
11,800
5,200
7.0
2.2
4213-33
40,000,000
39,000
593,000
38,200
13,200
5,900
7.0
2.4
4213-38
44,400,000
43,400
659,000
42,500
14,700
6,500
7.0
2.6
4213-42
50,400,000
49,200
748,000
48,200
16,700
7,400
9.0
2.6
4213-51
60,500,000
59,000
897,000
57,800
20,000
8,900
9.0
2.8
4213-59
70,600,000
69,000
1,100,000
67,600
23,400
10,400
9.0
3.1
4213-67
80,700,000
78,800
1,200,000
77,200
26,700
11,800
9.0
3.3
4213-77
90,800,000
88,600
1,300,000
86,800
30,000
13,300
9.0
3.6
4213-80
95,100,000
92,800
1,400,000
90,900
31,500
13,900
10
3.7
4213-85
101,000,000
98,500
1,500,000
96,500
33,400
14,800
9.0
3.9
4213-96
114,000,000
111,000
1,700,000
109,000
37,800
16,700
10
4.0
4213-112
133,000,000
130,000
2,000,000
127,000
44,100
19,500
10
4.3
Note: Primary
&
Radial Air Pressure = 15"w.c.
Radial
&
Primary Fuel Pressure = 8psi
Total fuel fl ow do esnt equal the sum of radial fuel and primary fuel. This is because the radial fuel fl owrate increases as the
primary fuel turns down.
Capacities | 4213 Burner
